MODEL				SPW180(E)
WELDER   & GENERATOR		Generating State(AC)	Rated frequency            (Hz)	50	60
			Cont.output                (Kw)	4.2	4.5
			Rated voltage(AC)           (V)	230	120/240
			Rated current(AC)           (A)	18.2	18.7
			Phase	Single phase
			Power factor	1
		Welding State(DC)	No-load welding voltage      (V)	58
			Rated welding current        (A)	160
			Welding operating voltage     (V)	30~36
			Welding current adjustment    (A)	80~180
		Rated speed		3000	3600
		Excitation system		Self-excitation
		Working mode		Continuous operation for 12 hours
		Connection mode		Transmission shaft rigid connection
DIESEL ENGINE		Model		F400(E)
		Type		Single-cylinder,4-stroke, direct-injection,air-cooled diesel engine
		Bore x Stroke(mm)		86x70
		Displacement(cc)		406
		Engine speed(mm)		3000	3600
		Max.output(hp)		8.8	10.0
		Cont.output(hp)		7.7	9.0
		Governor system		Centrifugal weight system
		Starting system		Recoil/Electric
		Lube oil capacity(L)		1.65
		Cooling system		Forced air-cooled system
		Start battery		12V,36Ah
UNIT	Fuel tank capacity(L)			12.5
	Dry weight(kg)			102
	Overall dimensions(LxWxH) (mm)			760x500x700
