Model |
FDP-100 |
FDP-200 |
FDP-300 |
FDP-400 |
| Outlet/Inlet dia. (mm/in) |
25(1¡±) |
50(2¡±) |
80(3¡±) |
100(4¡±) |
| Max. Capacity (l/min) |
83 |
600 |
1000 |
1800 |
| Max. Head (m) |
15 |
26 |
30 |
30 |
| Suction Head (m) |
4 |
8 |
8 |
8 |
| Self-priming Time (sec./5m) |
90 |
90 |
120 |
120 |
| Weight (kg) |
4 |
6 |
9 |
15 |
|
The engine requested to couple with the pump |
| Type |
Air-cooling 4-stroke petrol or diesel engine |
| Max. Output (3600rpm) |
1.5hp |
4hp |
5.5hp |
8hp |
| Connection |
Thread shaft direct connection |
| Shaft Thread |
3/4¡±x16 or M18x1.5 or customer¡¯s details |
| Shaft Length |
61.5mm or 78mm or customer¡¯s details |
|
The distance among 4 connecting holes (4-M8): 65.10mm |
